Surge Protector FAQ
Today more than ever, your world depends on electronics. Whether you are using a computer, watching TV, or charging a smart phone, the quality of your power is critical.
A surge is a sudden, quick increase in voltage. Though usually small and unnoticed by you, over time these surges can damage sensitive electronic equipment. In an average home, these small surges can occur many times a day.
Yes, refrigerators, freezers, furnaces, copier machines, laser printers, hair dryers, dishwashers, vacuum cleaners, and power tools—just to name a few—are responsible for creating surges.
Surges created by a storm or single lightning strike near your home can seriously damage electronics. Power lines and utility poles that are damaged by animals, fallen tree limbs, and car accidents can also cause surges. Surges can enter your home through telephone, CATV, or power lines.
You can start with installing a “circuit panel” or “service entrance” style surge protector (also referred to as a surge suppression device) in your home. This device either reduces electricity spikes, or stops them from entering the house all together. This will protect your larger appliances, such as ranges, water heaters, washers, dryers, dishwashers and motors. A qualified electrician or your local utility can ensure proper installation. Proper installation is key because even the best surge protector in the world is useless unless it is correctly installed.
But don’t stop here! To further protect your electronic equipment against surge damage, you need to install a surge protection device within fifteen feet of that equipment. This can be done with a simple plug-in unit or one that wires directly to your equipment.
The best way to protect yourself form surges is through the combination of service entrance surge protectors, and additional protection 15 feet from electronics.
Not necessarily. Damaging surges can enter your home through phone and cable circuits just as easily as power lines. The same rule applies as before: protect your phone and cable cords within fifteen feet of your equipment. At locations that combine electric power with either cable television or telephone, make sure that the surge protector protects everything.
Yes. A surge protection device is only as effective as the electrical grounding circuit that is made available to it. Surge protection devices divert surge current to grounding wires in your home and then ultimately to earth where they are safely diverted away from your equipment.
A qualified electrician or your local utility can make that determination for you. Since most permanently wired surge protectors will require an electrician for installation, this may be a good time to have your grounding examined. Additionally, surge protection strips are only effective if used on three-prong (grounded) outlets.
No. Like most products, surge protectors vary in quality. Careful attention must be paid to how a surge protector meets your requirements. Read the information on the box carefully and consult the information under the "Surge protector checklist" heading.
Look for surge protection devices that carry a “UL 1449” label. Surge protectors also carry a “joule” and/or “surge-current” rating. The higher the rating of these two categories, the better is the quality of the internal surge-stopping components. Another important performance characteristic is the “clamping voltage.” This is the voltage that the surge protector will let through to your equipment before it diverts it to ground. A quality device will have status lights that will display correct input wiring configuration and failure indicator lights or buzzers to signify whether the device is working properly. See the "Surge Protector Checklist" tab for more information.
Expect to pay about $45–$100 for a higher quality eight-outlet plug strip with an internal phone protector. Stay away from those $8 specials. A residential circuit panel-mounted surge protector of higher quality will cost in excess of $100.
No. A variety of conditions can indicate that it is time to replace surge protectors. Two of the most prevalent signals are a failure indicator light going off and/or a buzzer sounding. Some surge protection strips are also designed to permanently turn off upon failure.
Contact NGEMC's Energy Services team who can provide information about proper selection, installation and use.
- UL Listing (“UL 1449 Listed” is good. “UL 1449 Revision 2” is better).The following terms do not indicate adequate surge protection: “UL tested,” “meets UL,” and “UL.” The surge protector should indicate that it is “UL listed.”
- For a plug strip, the clamping voltage should be UL 330 volts, the surge-current rating should be at least 36,000 amps, and the joule rating should be at least 360 joules.
- For permanently installed surge protection, the clamping voltage should be no more than UL 400 volts, the surge-current rating should be at least 36,000 amps, and the joule rating should be at least 360 joules.
- Failure indicator light or buzzer
- Status light (for indicating proper wiring and grounding)
- Recessed on/off switch on strip surge protectors
- Multi-mode protection (line to neutral, line to ground, neutral to ground)
- Adequate plug spacing (wide enough to plug in power supplies if needed)
It is highly recommended that a surge protection device incorporates phone/modem and/or coax protection to cover all plug-in connections and any given piece of electronic equipment.
Surge Protector for TVs and VCRs should also include:
- Coax plugs
Surge Protectors for Computers, Telephones, and Telephone Answering Machines should also include:
- Telephone line plugs
We rely on electricity for almost everything. Being without it, even for a little while, is inconvenient and disruptive. North Georgia EMC works hard to keep power outages from happening, but it’s impossible to fully prevent them. As consumers and business owners, we can take precautions to protect equipment from damage caused by inevitable disturbances in the power system.
Most surges are caused by operational or electrical problems with equipment like compressors, motors, elevators, air conditioners, pumps, etc. Faulty wiring can also cause surges or load imbalances that damage equipment and electronics.
Surges caused by voltage disturbances outside the building can reach equipment through telephone, cable television or power lines. External causes of surges include storms, lightning, wind, accidents, equipment damage or failure, wildlife and vegetation.
Surge protection installed at the service entrance, distribution panels and points-of-use may reduce business downtime and help prevent damage to costly equipment:
- High-powered machines such as motors, compressors, HVAC;
- Computers, printers, fax machines and photo copiers;
- Sensitive electronics like security alarm systems, telemetry or monitoring networks, barcode scanners, and thermostats;
- Critical healthcare monitoring and life support systems;
- Telecommunications and data processing systems.
Power or voltage surges are brief bursts of energy caused by a sudden change in the electrical conditions of a circuit. Surge suppression devices regulate the voltage supplied to an electric device either by blocking excess voltage or diverting it to ground.
Surge suppression devices do not provide back-up power. An uninterruptible power supply (UPS) is a device that provides almost instantaneous temporary power when a permanent
power source fails.
- A UPS does not function as a standby generator or emergency power system, but works long enough to properly shut down protected equipment or to bring an auxiliary power source on line.
- A UPS is used to protect computers, data centers, telecommunications equipment or other electrical equipment where an unexpected power disruption could cause injuries, data loss or disrupt business processes.
Make sure that all systems have a common ground and enter the building within a few feet of each other. A qualified electrician and NGEMC can help determine if you have adequate grounding at your facility. Install surge protection in layers at different points in the electrical system:
- At the point of entry to protect against external disturbances.
- At distribution panels within the facility, especially if it includes large motors, welders, etc.
- At individual pieces of sensitive equipment and communication lines (phone cords, internet cables or coaxial cables – cable television or cable internet type connections).
Choose a product with the following features and information on the product packaging:
- Labeled as UL 1449 Listed or UL 1449 Revision 2 Listed; the following terms do not indicate adequate surge protection: “UL tested,” “meets UL,” and “UL.” The surge protector should indicate that it is “UL listed;”
- Joules (the amount of energy the suppressor can dissipate), ranges from 200 to several thousand, but the higher the number the better;
- Clamping voltage (the voltage at which the surge suppressor will divert the surge to ground) -- the lower the number the better -- typically 330 volts. Do not get a surge suppressor with a clamping voltage higher than 400 volts;
- A response time of less than one nanosecond;
- Failure indicator light or buzzer.
- Status light to indicate proper wiring or grounding.
- Recessed on/off switch on strip surge protectors.
- Multi-mode protection (line to neutral, line to ground, neutralto ground).
- Adequate plug spacing (wide enough to plug in power supplies if needed).
